MS Flanges Class 150 Manufacturers in India

MS Flanges Class 150 Manufacturers, MS Flanges Class 150 Exporters ,Mild Steel Flanges Class 150 India, Class 150 MS Flanges, Flanges Exporters, Mild Steel Flanges Manufacturers, MS Class 300 Flanges Suppliers

MS Flanges Class 150 Manufacturers in India. Leading suppliers dealers in Mumbai Chennai Bangalore Ludhiana Delhi Coimbatore Pune Rajkot Ahmedabad Kolkata Hyderabad Gujarat and many more places. Sachiya Steel International manufacturing and exporting high quality Mild Steel Flanges Class 150 worldwide. We are India's largest MS Flanges Class 150 Exporter, exporting to more than 85 countries. We are known as MS Flanges Class 150 Manufacturers and Exporters due to exporting and manufacturing on a large scale.

MS Flanges Class 150 Manufacturers in India: Types of MS Flanges Class 150-

We at Sachiya Steel International manufacture a wide variety of MS Flanges Class 150. There is a different types of MS Flanges Class 150 used for different needs.Our MS Flanges Class 150 are available in different sizes, grades and shapes. Sachiya Steel International manufactures and exports high-quality industrial MS Flanges Class 150. We are Exporters of the following MS Flanges -The classes for Slip on, Weld Neck, Ring-Joint, Tongue & Groove, and Raised-Face flanges are Class 150, Class 300, (Class 400 - unusual), Class 600, Class 900, Class 1500, and Class 2500.

Standard and Specifications Of MS Class 150

Specifications	Class 150 Flanges
ASME B16.5 Class 150 Flange size range	1/2" (15 NB) to 48" (1200NB) DN10~DN5000
Class 150 Flanges Standards	ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flanges.
Class 150 Flange Standard DIN	6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64
Class 150 Flange Standard JIS	5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K
Class 150 Flange Standard UNI	6Bar 10Bar 16Bar 25Bar 40Bar
Class 150 Flange Standard EN	6Bar 10Bar 16Bar 25Bar 40Bar
Main Types	Forged / Threaded / Screwed / Plate
Flange supporting material	Gasket, Ring Joint, Flange Bolts
Class 150 Pipe Flanges Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Most common types of Class 150 Flanges	Weld Neck Ring Flange (WNRF), Class 150 Slip-On Ring Flange (SORF), Class 150 Blind Ring Flange (BLRF), Class 150 Socket Weld Ring Flange (SWRF), Class 150 Threaded Ring Flange, Class 150 Lap Joint Ring Flange (LJRF), Class 150 Ring Type Joint Flange (RTJF), Class 150
Production technique	Forged, Heat treated and machined
Connect Type/ Flange Face Type	Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, , Groove
Special design	As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2") to 200 NB (8") Equal and Reducing Configurations Class 150 Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange
Test	Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector
Equipment	Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc

MS Flanges Class 150 Manufacturers in India: About MS Flanges Class 150 -

Sachiya Steel International is one of the largest MS Flanges Class 150 Manufacturers in India. Seamless pipe as the name suggests is a pipe without a seam or a weld-joint in contrast to Seam or Welded pipe. In a Seam or Welded pipe, the seam or the weld-joint is the weaker part of the pipe limiting the strength of the pipe to the strength of the weld-joint. Whereas the seamless pipe does not have any such joint and thus has uniform structure and strength all over the pipe body. Thus the seamless pipe can withstand higher pressure, higher temperature, higher mechanical stress and corrosive atmosphere and find wide applications in Oil and Gas, Refinery, Petrochemical, Chemical, Fertilizer, Power, Automotive, Bearing, Mechanical and Structural applications. We also known as Mild Steel Flanges Class 150 Manufacturers in India.

ANSI Class 150 Flange Dimensions in MM

Size in Inch	Size in mm	Outer Dia.	Flange Thick.	Hub OD	Flange Length	RF Dia.	RF Height	PCD	Socket Bore	No of Bolts	Bolt Size UNC	Machine Bolt Length	RF Stud Length	Hole Size	ISO Stud Size	Weight in kg
		A	B	C	D	E	F	G	H
1/2	15	90	9.6	30	14	34.9	2	60.3	22.2	4	1/2	50	55	5/8	M14	0.8
3/4	20	100	11.2	38	14	42.9	2	69.9	27.7	4	1/2	50	65	5/8	M14	0.9
1	25	110	12.7	49	16	50.8	2	79.4	34.5	4	1/2	55	65	5/8	M14	0.9
1 1/4	32	115	14.3	59	19	63.5	2	88.9	43.2	4	1/2	55	70	5/8	M14	1.4
1 1/2	40	125	15.9	65	21	73	2	98.4	49.5	4	1/2	65	70	5/8	M14	1.4
2	50	150	17.5	78	24	92.1	2	120.7	61.9	4	5/8	70	85	3/4	M16	2.3
2 1/2	65	180	20.7	90	27	104.8	2	139.7	74.6	4	5/8	75	90	3/4	M16	3.2
3	80	190	22.3	108	29	127	2	152.4	90.7	4	5/8	75	90	3/4	M16	3.7
3 1/2	90	215	22.3	122	30	139.7	2	177.8	103.4	8	5/8	75	90	3/4	M16	5
4	100	230	22.3	135	32	157.2	2	190.5	116.1	8	5/8	75	90	3/4	M16	5.9
5	125	255	22.3	164	35	185.7	2	215.9	143.8	8	3/4	85	95	7/8	M20	6.8
6	150	280	23.9	192	38	215.9	2	241.3	170.7	8	3/4	85	100	7/8	M20	8.6
8	200	345	27	246	43	269.9	2	298.5	221.5	8	3/4	90	110	7/8	M20	13.7
10	250	405	28.6	305	48	323.8	2	362	276.2	12	7/8	100	115	1	M24	19.5
12	300	485	30.2	365	54	381	2	431.8	327	12	7/8	100	120	1	M24	29
14	350	535	33.4	400	56	412.8	2	476.3	359.2	12	1	115	135	1 1/8	M27	41
16	400	595	35	457	62	469.9	2	539.8	410.5	16	1	115	135	1 1/8	M27	54
18	450	635	38.1	505	67	533.4	2	577.9	461.8	16	1 1/8	125	145	1 1/4	M30	59
20	500	700	41.3	559	71	584.2	2	635	513.1	20	1 1/8	140	160	1 1/4	M30	75
24	600	815	46.1	663	81	692.2	2	749.3	616	20	1 1/4	150	170	1 3/8	M33	100

MS Flanges Class 150 Manufacturers in India: Industrial MS Flanges Class 150 -

• Oil & Gas Industries
• Chemical Industries
• Automotive Industries
• Fertilizer Industries
• Petrochemical Industries
• Power Industries
• Mechanical and Structural Industries
• Refinery Industries

We are leading Exporters of MS Flanges Class 150 in more than 85 Countries worldwide.

MS Flanges Class 150 Manufacturers in India: Cities we supply MS Flanges Class 150 to -

Sachiya Steel International is manufacturer supplier of MS Flanges Class 150 in most of the major Indian cities in more than 20 states. We are leading supplier of MS Flanges Class 150 in Mumbai, Ahmedabad, Ludhiana, Delhi, Rajkot, Pune, Coimbatore, Chennai, Bangalore and many other cities. The complete list of cities we supply our MS Flanges Class 150 to is mentioned in the below table.

Sachiya Steel International is Leading manufacturers of Pipe Fitting in the following cities -
Bengaluru	Mumbai	Chennai	Hyderabad	Kolkata	Pune
New Delhi	Ahmedabad	Jaipur	Surat	Salem	Gandhinagar
Bhiwandi	Tiruppur	Sivakasi	Jamnagar	Thiruvananthapuram	Rajahmundry
Bhubaneswar	Vijaywada	Firozabad	Bokaro Steel City	Rajkot	Bharuch
Panna	Raipur	Cochin	Ludhiana	Panipat	Durgapur
Peenya	Pimpri-Chinchwad	Channapatna	Kharagpur	Nashik	Bareilly
Varanasi	Haldia	Rourkela	Bangalore	Moradabad	Indore
Visakhapatnam	Trivandrum	Pithampur	Dibrugarh	Angul	Gwalior
Coimbatore	Kannur	Nagpur	Vadodara	Rudrapur	Noida
Agra	Bhagalpur	Jamshedpur	Bhilai	Lucknow	kanpur
Thane	Bhopal

MS Flanges Class 150 Exporters in Mumbai: Sachiya Steel International Exports MS Flanges Class 150 to following countries -

MS Flanges Class 150 exporters in Saudi Arabia, Oman, Dubai, UAE, Mexico, Kuwait, Qatar, Iraq and many other countries. Sachiya Steel International has created a brand name for itself in the international market, by exporting large quantities of high-quality MS Flanges Class 150.

Sachiya Steel International is Exporter of Bolts Nuts Screws in the following countries -
Saudi Arabia	Oman	Kuwait	Netherlands	Iran
Bahrain	Qatar	UAE	Africa	China
Nigeria	Mexico	Canada	Venezuela	United Kingdom
United States	South Africa	Malaysia	Bangladesh	Turkey
Singapore	Sri Lanka	Australia	Brazil

Additional Information -

MS Flanges Class 150 Price: Rs.160-260 /Piece
Payment Modes: LC(Letter of Credit), TT(Telegraphic Transfer or Wire Transfer), Cheque and others.
Packaging: MS Flanges Class 150 are packaged with caution and safety so they reach our clients as good as he would expect.
Port of Dispatch: Mumbai or Kalamboli ports in Maharashtra state of India.
Note: The size, quantity, quality and other details of the MS Flanges Class 150 will be written/printed on the packaging of the shipment for convenience.
